SOUND DEVICES MixPre-6 II

Name: SOUND DEVICES MixPre-6 II
Brand: Sound Devices
SKU: sd.mixpre6ii
Price: 1150.0 EUR
Availability: InStock

€ 1.150,00

price (excl. VAT)

€ 1.391,50

incl. VAT

Out of stock >

ADD TO WISHLIST REMOVE FROM WISHLIST

SKU: sd.mixpre6ii

Brand: Sound Devices

Categories:

DSLR-audio, DSLR-audio Mixers/Recorders

CLICK TO SEE RELATED PRODUCTS

Description
Specifications
In the Box

If you record field audio, sound effects, podcasts, voice-overs, music, audio for film or are just starting your audio journey, the MixPre-6 II is for you! With four crystal-clear, ultra low-noise Kashmir preamps, you can record multiple actors, multiple podcasters or audio for film with superior quality, all the way up to a 32-bit float bit rate and a 192 kHz sample rate. This newest generation of Sound Devices' award-winning MixPre Series has been redesigned for increased performance and an astounding 142 dB of dynamic range.

Your MixPre-6 II is highly customisable to your needs. Record internally to a compatible SD card on set or stream your podcast over USB to your computer at home. Power with your computer, wall power or record in the middle of nowhere with AA or Sony L-mount batteries. Adjust limiters, bit depth, sample rates, gain, pan, low-cut, phase inversion and phantom power to your liking. Trigger your camera with the internal timecode generator or feed timecode in via HDMI or aux in.

Your MixPre-6 II is rugged, lightweight and small, so you can throw it in a bag or mount it to a tripod or camera - or get situated on set with our Wingman App and one of our four supported USB control surfaces. With the superior sound and build quality that you can expect from the industry leader in production audio recording, your MixPre-6 II can capture audio for any application.

Are you a songwriter or musician? Buy the Musician Plugin to easily create a song using your MixPre-6 II as a standalone recorder or USB interface. Use onboard features like overdub, bounce, reverb and tracking to a metronome. Create Music Projects to lay down backing tracks and use them live or at home for writing or practicing. Capturing your song ideas has never been easier! While in Music Mode, the MixPre-6 II is limited to six simultaneous live inputs. Using multiple microphones with your MixPre-6 II? Enable the MixAssist Plugin to reduce unwanted microphone and room noise while recording.

Download the free Ambisonics Plugin on the Sound Devices website to record in 360° audio and monitor binaurally with an ambisonic microphone like the Sennheiser AMBEO and your MixPre-6 II.

FEATURES:

four ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set or with a computer
create a mix using the built-in 6 x 2 portable mixer
record up to 8 tracks to an SD card and backup to a USB thumb drive
8-in, 4-out USB audio interface streams to your computer via USB-C
choose bit depths from 16 to 32-bit float, sampling rates from 44.1 kHz to 192 kHz
internal LTC timecode generator, timecode in/out via aux in/stereo out
timecode and record triggering via HDMI
USB-A for control surfaces, keyboards and auto-copy to USB drive
in-unit ISO mixing, gain, pan, low-cut, phase inversion and phantom power
sunlight-readable color touch screen and LED metering
lightweight, durable and small: perfect for bag use, mobile recording or studio
powerful 300 mW+300 mW headphone amp allows clear and accurate reference
customise with plugins from the Sound Devices plugin store
pre-roll buffer of 10 seconds
includes a MX-4AA Battery Sled (batteries not included), MX-PSU AC Power Supply and USB-C to USB-C cable

AUDIO INPUTS:

frequency response: 10Hz to 80kHz +/0.5dB re 1kHz @ 192kHz sample rate
THD + Noise: 0.005% max (@1kHz, 22-22kHz BW, gain=20dB, -10dBu in)
audio inputs ADC 32 bit precision: 142 dB dynamic range min (A-weighted, gain=10dB, fader=0dB)
equivalent input noise: -130dBV (-128dBu) max (A-weighting, gain=76dB, 150 Ohm source impedance)
mic inputs XLR active-balanced: 4k input
line inputs XLR active-balanced: 4k input
aux/mic in: 3.5mm TRS, 2-channel unbalanced, 100k input
line inputs 1/4-inch TRS active-balanced, 4k input
USB audio: input 4 channels
all inputs fully RF-filtered and overload protected
mic input gain: +6dB to +76dB
line input gain: -20dB to +30dB
fader gain: -inf to +20dB
headphone gain: -inf to +20dB
total gain, mic-to-recording (max): +96dB
aux in (mic): gain = +10dB to +40dB
aux in (line): gain = -10dB to +20dB
total aux gain including fader (mic-to-recording): +60dB
maximum input level mic XLR: +14dBu (limiters on or off)
maximum input level line XLR: +28dBu (limiters on or off)
maximum input level aux in (mic): -10dBu
maximum input level aux in (line): +10dBu
low cut filters 40Hz to 160Hz (adjustable), 18 dB/oct. first stage analog, subsequent stages digital
microphone powering mic XLRs: 48V via 6.8k resistors, 10mA each
microphone powering mic 3.5mm: 3V @ 3k source
limiter at all gain stages, range > 40dB. First stage analog, subsequent stages digital
adjustable threshold, ratio and release

AUDIO OUTPUTS:

DAC feeding stereo out, headphone out 32 bit precision: 115dB dynamic range (A-weighted)
stereo out 3.5mm TRS stereo unbalanced, 500 Ohm output, +7.8dBu max output level
headphones out 3.5mm TRS stereo unbalanced, 300mW + 300mW, for use with any impedance headphones

USB:

USB audio interface (USB-C): 8-in/4-out, 44.1 to 96 kHz, 16/24/32-bit integer, 32-bit float, class-compliant USB 2.0 high speed or ASIO (supplied via download)
USB mass storage (USB-C): USB 2.0 high speed
USB keyboard (USB-A): text entry and control
USB thumbdrive (USB-A): manual or auto-copy to drive
USB midi control surface (USB-A)

RECORDING:

maximum record tracks 8 tracks: stereo mix + 6 ISOs
sampling frequency: 44.1, 47.952, 48, 48.048, 96, 192 kHz
bit depth: 16, 24, 32 float
recording storage type: SD, SDXC, SDHC Card (USB thumbdrive, copy only)
max storage size: 512 GB (SDXC)
recording storage card format: exFAT
file type: polyphonic WAV

TIMECODE:

timecode modes free run, time of day (file stamped w/current ToD), rec run, ext LTC (file stamped w/incoming LTC on 3.5mm aux in), camera TC (file stamped w/incoming TC from cameras that output TC)
timecode frame rates auto-detects (fps): 23.98 (same as 23.976), 24, 25, 29.97DF, 29.97ND, 30, 30DF
3.5 mm aux in timecode input 20k Ohm impedance, 0.3 V-3.0 V p-p (-17 dBu -/+3 dBu)
3.5 mm stereo out timecode output 1k Ohm impedance, 3.0V p-p (+12 dBu)
HDMI TC Reader via HDMI
sample/timecode accuracy: 0.2 ppm (0.5 frames per 24 hours)

REMOTE CONTROL:

Bluetooth LE: wireless control using Wingman app
HDMI (micro): auto-record start/stop trigger from cameras that output record flag over HDMI
timecode: auto-record start/stop trigger via aux in timecode

TOUCH SCREEN:

320x256, 1.6-inch, color, sunlight-viewable IPS LCD

POWER:

AA batteries: 4x AA sled (included), 8x AA sled (optional accessory), NiMH recommended
from computer: bus-powered via USB-C port, optional MX-USBY cable, connects one USB-C to two USB-A ports
AC Adapter: MX-PSU (included) power supply wall adapter w/ USB-C connector, 15W, has 4 adapter plugs for US, UK, AU & Europe
L-Mount: optional sled for 2x (hot-swappable) Sony L-type Li-ion batteries

ENVIRONMENTAL:

operating: -20°C to 60°C, 0 to 90% relative humidity (non-condensing)
storage: -40°C to 85°C

DIMENSIONS:

measures: 36mm x 166 mm x 118 mm (H x W x D)
weight: .56 kg (unpackaged, without batteries)
