Description
The DSQD half rack receiver with analog and digital Dante network audio outputs utilizes the Lectrosonics signature digital architecture with remarkable audio quality and ultra-low latency. The receiver includes an extended operating range rivaling the best analog and Digital Hybrid Wireless systems with continuously tunable tracking filters covering 470 to 614 MHz.
The DSQD receiver is a four-channel design with a host mainframe that contains the DSP, microprocessor, antenna multicoupler and control interface. Antenna ports on the rear panel accept input from remote antennas, with a loop-thru output to another mainframe using the internal multicoupler. A kit is also available to mount antenna inputs (BNC connectors) on the front panel.
FEATURES:
- four-channel, half-rack design
- continuously tunable tracking filters covering 470.100-614.375 MHz
- compatible with D Squared, DSW, Duet and Digital Hybrid Wireless transmitters
- built-in wideband antenna multicoupler with loop-thru for additional receivers
- antenna bias power enabled from the front panel
- IR bi-directional port for transmitter setup
- analog and Dante audio outputs with TalkBack (in applicable RX modes)
- Ethernet and USB interface
Specifications
- operating spectrum: 470.100 to 614.375 MHz
- frequency adjustment range: 25 kHz
- steps sampling size and rate: 24-bit, 48 kHz
- digital modulation: 8PSK with forward error correction
- data encoding: proprietary ADPCM
- encryption: AES 256-CTR (per FIPS 197 and FIPS 140-2)
- system latency digital output: D2 mode 0.75 ms plus Dante, Duet mode: 1.4 ms plus Dante, hybrid modes: 2.0 ms plus Dante
- system latency analog output: D2 mode 1.25 ms, Duet mode: 1.9 ms, Hybrid modes: 2.5ms
- frequency response: 20 Hz-20 KHz, +\-1 dB
- THD+N: 0.05% (1 KHz @-10 dBFS)
- dynamic Range: 108 dB A-wtd, NR=NORMAL
- adjacent channel isolation: >85 dB
- diversity technique: noiseless antenna switching
- sensitivity: -98 dBm
- antenna inputs/outputs: dual BNC female, 50 ohm impedance
- audio outputs (XLR): balanced, -35 to +8 dBu
- headphone: 3.5mm phone jack
- Dante model only: RJ45 Gigabit Ethernet
- AES3 model only: TA3M
- external DC Power: 7 to 18 VDC, 2.5A (max)
- weight: 880 grams
- dimensions: 213 x 44.5 x 187 mm
INCLUDED ACCESSORIES:
- 1x USB cable
- 1x bracket, rear tie
- 1x bracket, front tie
- 1x rack flange bracket
- 1x rack "D" handle
- 1x SCR10 cap screw
- 1x spacer
- 1x rubber feet, large, stick on
- 1x hex key
- 1x hole plug
- 2x right angle BNC antenna, block 20
- 2x right angle BNC antenna, block 22
- 1x AC power supply
